Stainless steel connecting plates are designed to join straight sections of cable trays or ladders, or to connect trays to fittings such as bends, tees, or crosses. They provide structural integrity and maintain alignment between tray sections, preventing sagging or misalignment in cable management systems. These plates also ensure electrical continuity across the joined sections, which is important for grounding and safety compliance .
Most high-quality connecting plates are made from SS 316 stainless steel, which offers superior corrosion resistance, especially in harsh or industrial environments. Stainless steel forms a passive chromium oxide layer that protects the underlying metal from oxidation and self-repairs if damaged. For welded or machined surfaces, additional pickling and passivation treatments are applied to remove impurities and restore corrosion resistance .
Connecting plates come in various types to suit different cable tray systems:
These plates are typically fastened with screws, nuts, and washers supplied with the plate. The number of plates required depends on the width and load of the cable tray. Proper installation ensures both mechanical strength and electrical continuity, in accordance with standards such as IEC61537 and NEMA .
Stainless steel connecting plates are widely used in:
